48V Counterbalance Forklift Truck Electronic Control Comfortable Design

Name: 48V Counterbalance Forklift Truck Electronic Control Comfortable Design
Brand: REACH
Price: 1 USD

Quality 48V Counterbalance Forklift Truck Electronic Control Comfortable Design wholesale

Brand Name : REACH

Model Number : CQD15M

Certification : CE, TUV

Place of Origin : Zhejiang, China

MOQ : 1 set

Price : Negotiable

Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 100 sets per month

Delivery Time : 25 - 30 days

Packaging Details : Nude

Capacity : 1500kg

Max. lifting height : 3000/5000/6200mm

Fork dimensions : 35/100/1070mm

Aisle width for pallets 1000*1200 crossways : 2800mm

Aisle width for pallets 800*1200 lengthways : 2850mm

Travel speed, load/unload : 7/7.2km/h

Battery : 48V400AH

Contact Now

1500kg counterbalanced electric narrow aisle truck mast reach distance 600mm

Quick Details:

Product name: Counterbalanced electric narrow aisle truck CQD15M

Capacity: 1500kg

Max. Lifting height: 3000/5000/6200mm

Fork dimension: 35/100/1070mm

Travel speed, load/unload: 7/7.2km/h

Lift speed, load/unload: 0.19/0.2m/s

Lowering speed, load/unload: 0.5/0.4m/s

Aisle width for pallets 1000*1200 crossways: 2800mm

Aisle width for pallets 800*1200 lengthways: 2850mm

Battery: 48V400AH

Advantages:

The wide and strong forklift chassis ensures the sufficient stability of the forklift and the lifting height 3-6.2meters.
Using high quality imported Krupp mast to improve the service life and stability.
Spacious and comfortable cabin and adjustable seat, more embodies the humanized design of the narrow aisle truck.
High speed limit setting, when the forks lift up to a certain height, the narrow aisle truck speed will automatically decline, to ensure the safety of high-altitude operations.
With double electric control system, the lifting of goods and the driving of forklift can realize stepless speed change.
Full hydraulic power steering system makes the steering flexible and portable.
The braking of the driving motor is controlled by the electronic control system, so that the starting, driving and braking of the forklift are more effective.
There are two ways to install the battery: 1. side pull out, make the battery replacement more convenient. 2. the battery is pushed out and pulled in automatically with the mast, which is easy for daily maintenance.

SPECIFICATIONS
Model		CQD15M
Power		battery
Operate type		seated
Capacity/rated load	kg	1500
Lifting height	mm	3000/5000/6200
Load center distance	mm	500
Drive wheel	mm	280*100
Fork wheel	mm	285*80
Tilt of mast/fork carriage forward/backward	Grad	2,3(mast)/ ~ / ~
Height, mast lowered	mm	2086/2240/2640
Free lift	mm	~ /1700/2100
Height, mast extended	mm	3800/5800/7000
Height of overhead guard(cabin)	mm	2114
Seat height/stand height	mm	920
Height of crura	mm	270
Overall length	mm	2390
Length(barring fork)	mm	1850
Overall width	mm	1100
Fork dimensions	mm	35/100/1070
Reach distance	mm	600
Aisle width for pallets 1000*1200 crossways	mm	2800
Aisle width for pallets 800*1200 lengthways	mm	2850
Turning radius	mm	1740
Travel speed, laden/unladen	km/h	7/7.2
Lift speed, laden/unladen	m/s	0.19/0.2
Lowering speed, laden/unladen	m/s	0.5/0.4
Battery	V/Ah	48/400
Service weight	kg	2400/2800/2900
